Jiangsu Starlight Electricity Equipments Co., Ltd. Standard Control Panel BFK620
Features: Jiangsu Starlight Electricity Equipments Co., Ltd. Standard Control Panel uses micro processing technique integrating digital, intelligent and network techniques, which can carry out functions including:
-Auto start/stop
-Auto/manual switch
-Data display:Voltage, current, frequency, load applied power measure,active power, average power, KWhr, Kvarhr,RPM,oil pressure Bar/PSI,Auxiliary analog output1，2，battery voltage, opporation time.
-Alarming,Warning, fault diagnose and communication to PC with RS485,RS232,USB port
-Optional CANbus communication port to read ECU engine data.
-Working Environment -40 to 70’C
The controller uses LCD display, optional Chinese and English display interface with easy and reliable operation.
BFK-H3310
The new generation of single gen-set auto control module, the new design more focused on customers needs. It improves the quality aimed to satisfy different gen-set utility needs.
BFK-H3310 includes all features of BFK620
MRS-10/16 Auto control system
Features:
MRS-10/16 controller comes with large LCD screen; full English& Chinese operation. The control panel has strong control function, easy to operate.
The C-10/16 Auto control system can carry out functions including:
-Auto start/stop;
-Easy operation button, with LED lighting & LCD display
-Data can be measured and modified directly on module/PC
-Gen-set 3 phase protection
-Generator set measurement (50/60Hz) in units:
U1-U3,I1-I3,Hz,KVA, KW, KVAr,KWH.
-Optional input and output port
-Fault history
Remote Feature:
MRS-10 can receive remote output signal from ATS and realize auto start and stop of generators.
MRS-16 can realize all functions of MRS10, add RS232 interface, which can communicate with PC to realize remote operation.
AMF-25 Auto mains failure controller can realize all functions of MRS16, furthermore can detect ATS and control directly.
For more information, please consult with our professionals at sales@starlight-genset.com
